SPECIALIZED

Epic EVO Pro LTD

Epic EVO Pro LTD

SKU: 94823-1103

R 155,000.00
R 170,000.00 R 155,000.00
Sale Sold out
Tax included.
Size
Color

Only 1 left in stock

Epic EVO Pro LTD

Trail-worthy, meet drool-worthy. Perfect, now that introductions are out of the way, let’s do our best to try and grasp the fact that the Epic EVO Pro LTD manages to channel the Epic’s standard-setting pedaling efficiency while delivering jaw-dropping on-trail capability—and look darn good doing it.

While the Epic EVO sees a seemingly modest 20-millimeter increase in suspension travel up front over its Epic stablemate and just 10-millimeters out back, we’ve worked overtime to make sure it’s been implemented in a way that’ll have you saying ‘Whoa!’ as soon as you hit your first stretch of singletrack.

Meticulously engineered to retain as much of the Epic’s standard-setting efficiency as possible, the EVO’s new suspension kinematics work in concert with Rx XC Tune customized suspension front and rear to ensure you're able to make the absolute most out of every inch of travel on tap, while still offering increased anti-squat characteristics for improved pedaling efficiency.

With plenty of practice at staying ahead of the curve, the Epic EVO now lays claim to the most capable iteration of our Progressive XC Geometry ever to grace an Epic. It’s also more versatile than ever thanks to a new flip chip-equipped rear end that allows riders to adjust headtube angle and bottom bracket height to easily customize Epic EVO’s handling characteristics.

Dressed to impress, the Epic EVO Pro LTD sports top-shelf RockShox suspension front and rear to keep things poised when the going gets rough, while the silky shifts and rock-solid performance of SRAM's 12-speed X0 Eagle AXS group will never go out of style.

  • Flip It To Rip It: Tune the ride of the Epic EVO’s FACT 11m carbon frame to match your preferred handling characteristics with flip-chip simplicity that allows riders to reduce the EVO’s headtube angle by half a degree while lowering bottom bracket height by 10 millimeters.
  • Pairing the stiff yet lightweight SID Ultimate chassis with RockShox's lightest-ever Charger Race Day damper makes for quite the package, impressively cutting weight while still managing to pack in truly impressive levels of performance, precsion, and control.
  • The X0 Eagle AXS groupset utilizes the proven backbone of SRAM 1x, 520-percent gear range, a more secure and longer-wearing X-Sync 2 chainring, and the resilience of an aluminum cage paired with the connected components of Eagle AXS.
  • Descending from a long World Cup lineage, hand-built Roval Control Carbon wheels feature a modern 29-millimeter internal-width hookless rim and straight-pull DT Swiss 350 hubs to maximize strength, ride quality, and durability while keeping weight to a minimum.
View full details

Technical Specifications

COCKPIT

SeatPost

Bike Yoke Revive, 30.9mm, SM: 125, MD: 160mm, L/XL: 185mm,

Saddle

Body Geometry Power Expert

Handlebars

Roval Control Rise Carbon Handlebar, 760mm wide, 20mm rise, 35mm

Tape

Specialized Trail Grips

Stem

TruVativ Descendant 35, 35mm clamp, 60mm



WHEELS

Rear Hub

DT Swiss 350 straight-pull, 6-bolt, DT Swiss Ratchet EXP, 12x148mm thru axle, Microspline freehub body, 28h straight-pull

Front Hub

DT Swiss 350, 6-bolt, 15mm Thru-axle, 110mm spacing, 28h straight -pull

Spokes

DT Swiss Comp Race

Rims

Roval Control, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 28h

Front Tire

Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35

Rear Tire

Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35

Inner Tubes

Specialized Turbo Tube



FRAMESET

Frame

FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm UDH compatible rear spacing, internal cable routing, 110mm of travel

SWAT

SWAT CC steerer tube integrated tool with chain tool and link, detachable SWAT box

Seat Binder

Specialized Alloy, 34.9mm



SUSPENSION

Rear Shock

RockShox SID LUXE ULTIMATE, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm

Fork

Rockshox SID ULTIMATE, Charger Race Day Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel



DRIVETRAIN

Shift Levers

SRAM AXS POD Controller

Bottom Bracket

SRAM DUB Threaded Wide

Chain

SRAM X0 Eagle Flat Top

Rear Derailleur

SRAM X0 Eagle AXS

Crankset

SRAM X0 Eagle Crankset, 170mm/175mm

Cassette

SRAM X0 Eagle 10-52t

Chainrings

32T



BRAKES

Front Brake

SRAM Level Silver Stealth, 4-piston caliper, hydraulic disc, stealth, 180mm rotor

Rear Brake

SRAM Level Silver Stealth, 4-piston caliper, hydraulic disc, stealth, 180mm rotor



* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.




Geometry



 SMLXL
Crank Length170mm170mm175mm175mm
Handlebar Width760mm760mm760mm760mm
Stem Length60mm60mm60mm60mm
Saddle Width155mm143mm143mm143mm
Seatpost Length125mm160mm185mm185mm
Stack593mm597mm611mm629mm
Reach406mm436mm460mm485mm
Head Tube Length95mm100mm115mm135mm
Head Tube Angle66.5°66.5°66.5°66.5°
BB Height336mm336mm336mm336mm
BB Drop36mm36mm36mm36mm
Trail114mm114mm114mm114mm
Fork Length, Full530mm530mm530mm530mm
Fork Rake/Offset44mm44mm44mm44mm
Front Center697mm729mm759mm792mm
Chainstay Length438mm438mm438mm438mm
Wheelbase1132mm1164mm1194mm1227mm
Bike Standover Height779mm781mm793mm804mm
Seat Tube Length400mm430mm470mm520mm
Seat Tube Angle74.8°74.5°74.5°74.5°
Top Tube Length, Horizontal567mm602mm629mm659mm
